1. Materials
316L low-carbon stainless steel powder is sintered in an inert atmosphere using INOCO’s proprietary process. Before sintering, the metal powder is pressed, and no binders or other substances are used.
Metal powder sintered porous filter elements are made from various types of stainless steel, Monel alloy, Inconel alloy, Hastelloy, Ti metal, etc., as raw materials. The metal sintered filter elements retain the inherent corrosion resistance and high-temperature resistance characteristics of these metals.
Metal powder sintered filter elements can operate in high-temperature gas environments up to 1050 ℃ and are also suitable for various acid, alkali, salt solutions, and reducing or oxidizing atmospheres. They can handle a wide range of difficult gas and liquid materials under extremely broad chemical conditions.
Materials and Temperature
|
Code
|
Material
|
Maximum Operating Temperature
|
|
A
|
Bronze
|
300
|
|
B
|
Stainless steel, Nickel
|
400
|
|
C
|
Monel Alloy
|
500
|
|
D
|
High-temperature Alloy (INCONEL600)
|
800
|
|
E
|
Hastelloy
|
930
|
|
F
|
Titanium
|
250
|
2.Filtration Accuracy
Absolute accuracy:
1um~20um in liquid
0.01um~20um in gas
3.Advantages
No media shedding or dirt unloading.
Wide high and low temperature adaptability and chemical stability.
Asymmetric structure, not easy to clog, easy to back blow.
Integral sintered metal material, high strength, oxidation resistance, corrosion resistance, high mechanical strength.
High porosity, large filtration flux.
High differential pressure resistance, the pressure difference between the inside and outside of the filter element can reach 10KG.
4.Operating Conditions
Maximum Forward Differential Pressure: 80 ℃ 3.5kg/cm² 232 ℃ 3.2kg/cm².
Maximum Reverse Differential Pressure: 80 ℃ 3.5kg/cm² 232 ℃ 2.3kg/cm².
Selecting appropriate materials. Using metal sealing technology, the operating range can reach: 168 ℃ ~ ~ ~ 950 ℃.
5.High porosity up to 50%, low pressure drop, high flow rate, strong dirt holding capacity.
6.Model Specifications
|
Model
|
DS-M-01
|
DS-M-02
|
DS-M-03
|
DS-M-05
|
|
Diameter mm mm
|
40、50、60、80、106
|
|
Length mm
|
250、500、750、1000、1500、2000
|
|
Filtration Accuracy
|
0.1、0.5、1、2、3、5、7、10、15、20
|
|
Connection Type
|
Screw thread(M20,M30,NPT1”,etc.);222,226
|
|
|
Flange type, Flat type
|
Fine Chemicals
Fluidized Bed Hydrogenation Process for Hydrogen Peroxide Production
Oily Sludge Treatment System
Fiber Spinning
Aromatic Fragrances
Coal chemical industry chain
Coal gasification filtration system, coal gasification to ethylene glycol, etc.
Food, beverage, and water treatment
Flue gas desulfurization wastewater treatment
Filtration and clarification of wash water, injection solutions, beverages, etc.
Gas Filtration and Purification
Silicon Powder Transport Process Exhaust Filtration
Trichlorosilane Syngas Filtration
Trichlorosilane Exhaust Filtration
Silicon Tetrachloride Exhaust Filtration
Incineration Exhaust Gas Filtration
Shell Coal Gasification High-Temperature Gas Filtration
Olefin Plant High-Temperature Gas Filtration
Instrumentation and Medical Gas Protection
New Coal Chemical Gas Filtration
Metal powder sintered porous components are formed using cold isostatic pressing (CIP) and then sintered at high temperatures.
Coating Technology: Patented coating technology improves absolute filtration accuracy, achieving a maximum absolute filtration accuracy of 0.5μm in liquid filtration and up to 20nm in gas filtration.
